CNPC USA

Fracturing Fluids Labs

The Fracturing Fluids Lab is a specialized facility dedicated to the analysis, formulation, and testing of fracturing fluids used in hydraulic fracturing operations. Our lab ensures optimal performance by evaluating viscosity, proppant transport capability, fluid loss control, and chemical stability under various reservoir conditions. Equipped with state-of-the-art instruments, we conduct comprehensive testing to enhance fracture efficiency, minimize formation damage, and ensure environmental compliance. Our team of experts provides customized solutions to meet the unique challenges of hydraulic fracturing, supporting both research and field applications.

Polymer Synthesis Setup

Polymer Synthesis Setup

Reaction setup to produce dry friction reducers or liquid inverse emulsion friction reducers

Meat Grinder

Meat Grinder

An instrument used in polymer gel processing to cut large polymer gels into smaller pieces for efficient drying and further processing.

Fluid bed dryer

Fluid bed dryer

Efficiently simulates industrial drying by fluidizing materials for fast, uniform moisture removal.

Grinder

Grinder

To efficiently grind dry polymers into smaller particles for improved processing and application.

Sonic Sifter

Sonic Sifter

Separates dry polymer powders by particle size using sound waves and air pulses to obtain the final desired product.

SEC-MALS (Size Exclusion Chromatography with Multi-Angle Light Scattering)

SEC-MALS (Size Exclusion Chromatography with Multi-Angle Light Scattering)

An analytical device used to determine the molecular weight, size, distribution, and structural analysis of high molecular weight polymers.

Model 6700 Chandler Friction Flow Loop System

Model 6700 Chandler Friction Flow Loop System

Fully automated system to measure the friction pressure of fluids at ambient temperature.

Model 5600 Chandler Shear History Simulator

Model 5600 Chandler Shear History Simulator

The system can be operated manually or can be run from the software to evaluate the effect of shear upon a fluid.

Fann 35 Viscometer

Fann 35 Viscometer

Measure the viscosity of the fluid at ambient temperature

Model M3600 Grace Viscometer

Model M3600 Grace Viscometer​

Measure the viscosity of the fluid at ambient temperature

Model 5550 Chandler Viscometer

Model 5550 Chandler Viscometer

Measure the viscosity of the fluid at high temperature & high pressure

Kinexus Ultra+ Malvern Rotational Rheometer

Kinexus Ultra+ Malvern Rotational Rheometer

Measure & understand of the flow characteristics of the fluids from viscosity to viscoelasticity

M4085 Grace Fluid Loss Tester

M4085 Grace Fluid Loss Tester

Measure the fluid loss properties under elevated pressure & temperature conditions

Model M9106 Grace Saturator System

Model M9106 Grace Saturator System

Saturate the cores in brine with high pressure at ambient temperature

Model 6100  Chandler Formation Response Tester

Model 6100 Chandler Formation Response Tester

Design to study the effect of fluid treatments on the permeability of core samples and formation damage at high temperature and high pressure

Core Permeability Tester

Core Permeability Tester

An instrument measures the ability of reservoir rock to transmit fluids, aiding in reservoir evaluation and production optimization.
