Quality Assurance & Calibration Lab
A specialized facility dedicated to ensuring the precision, reliability, and compliance of industrial measurement tools. We conduct dimensional analysis, material hardness verification, and environmental assessments to uphold the highest quality standards.
1. Dimensional Analysis
Optical Comparator (20-1600 ST)
Unit #TIC 339 featuring 10x to 50x magnification for precision visual inspection of part profiles.
MIC TRAC System
Unit #TIC 297 providing precision dimensional measurement over a 0-24 inch range.
Height Gage (0-24 Inch)
Unit #TIC 342 for high-precision vertical dimensional validation of industrial tools.
Outer Diameter Micrometer Set
Unit #TIC 340 covering 0 to 12 inch OD measurement applications.
Precision Digital Scale
High-accuracy scale system for material mass validation and consistency checks.
Portable Hardness Tester
Unit CNPC 099 for rapid material hardness verification of industrial components.
Impulse Sealer with Cutter
Unit #TIC 299 for specialized laboratory component packaging and sealing.
2. 3D Metrology
Master 3D Gage System
Unit #TIC 343 running Varisurf 3D CAM software for complex geometry validation and digital mapping.
3. Thermal Calibration
Temperature Calibration Unit
Unit #TIC 356 dedicated to verifying the accuracy of thermal sensors and instruments.
FLUKE Temperature Gun
Unit #TIC 018 for high-accuracy non-contact thermal measurements.
4. Ultrasonic Inspection
Ultrasonic Gage (CheckLine TI-CMXDLP)
Unit #TIC 357 for precision non-destructive testing and material analysis.
Pipe Wall Thickness Testing
Specialized inspection setup for verifying the wall thickness integrity of tubular components.
Laboratory Contact Info
Expert: Dwayne Kasper
Email: dwayne.kasper@cnpcusa.com
Phone: +1 (713) 972-6599
Address:
22130 Merchants Way, Ste. 190
Katy, TX 77449
