G-4 Polymer Particles for Water Conformance
G-4 is a polymer expandable emulsion particle system developed by CNPC USA specifically for oil fields undergoing long-term water flooding. It is designed for deep profile control and water plugging in wells with high water production and low oil displacement efficiency.
Key Advantages
- Liquid form for easy in-situ addition
- Low initial solution viscosity with good injectability
- Controllable expansion ratio (3–20 times) and time (5–60 days)
- Stable blocking characteristics
- Application temperature: 40–90 °C
Typical Properties
- • Appearance: Off-white opaque liquid
- • Polymer Activity: 30%
- • Specific Density: 1.02–1.06 g/cm³
- • Product Viscosity: 400–2000 cp
- • Initial Particle D50: 5–15 µm
- • Flash Point: > 210 °F (100 °C)
Applications & Treatment
G-4 particles can be easily dispersed into injection water during flooding operations. Recommended treatment concentrations typically range from 0.5% to 1.5% (1,500–5,000 ppm particle concentration), depending on specific reservoir conditions and injection designs.
Packaging & Storage
- Available in 265 Gal (900 Kg) totes (IBCs) or 55 Gal (180 Kg) drums.
- Store in original containers with closed lids in a dry, cool, and well-ventilated location.
